TASSCO product sheet

Made in USA

Through-hardened heavy-gauge wear plate · 1¼″ to 5″

TASSCO HD

Hard through 5 inches. Tough at −50°F.

Aim · 1¼″–3″
450BHN
Charpy CVN @ −50°F
27ft-lb
Stocked thickness
1¼–5in
Cat 6040 shovel bucket lined with 2 inch TASSCO HD wear bars and 4 inch formed skis
Pictured: Cat 6040 shovel bucket, 2″ HD wear bars, 4″ formed skis

Tested through the section

Heavy AR plate is often hard on the surface and soft in the core. HD is through-hardened, and every plate is Brinell-tested to a range set by thickness: 430–500 BHN (aim 450) for 1¼″–3″, and 400–460 BHN (aim 430) over 3″ to 5″.

01 What it is

HD is through-hardened plate for heavy sections that take impact. Its lean-carbon, rich-alloy chemistry lets a full 5-inch section harden evenly to the core. Vacuum degassing and calcium treatment leave very few inclusions for a crack to start from. The result is even hardness face to face, with the toughness to take repeated hard hits without cracking or warping.

Yield
162.6 ksi
Tensile
219.2 ksi
Elongation (4D)
13%

02 Why it works

Tough when it's cold.

In a Charpy test, a notched bar of HD is chilled, then broken with a swinging hammer. The number is the energy it absorbs before it snaps. Higher means tougher.

Steel turns brittle as it gets colder. From +70°F down to −50°F, HD keeps over 60% of its toughness, so a liner loaded with frozen ore still takes hits without splitting at the weld. Brittle plate can fall to single digits in the cold.

Charpy CVN · ft-lb · 2″ plate
TemperatureEnergy absorbed
+70°F43.5 ft-lb
0°F36.0 ft-lb
−20°F30.2 ft-lb
−50°F27.0 ft-lb

ASTM A370 · Average of 3 longitudinal + 3 transverse specimens.

Clean steel, every plate.

  • Steelmaking

    EAF, vacuum degassed.

  • Clean steel

    Calcium treated, clean fine-grain steel.

  • Heat treatment

    Quench and temper.

  • Forming

    Press-brake formable.

03 Applications

Where it earns its keep

  • Shovel & dipper liners
  • Loader buckets & base edges
  • Crusher liners & impact zones
  • Truck box drop zones
  • Hammers
  • Sprockets
  • Wear bars & side guides
  • Mobile equipment liners

04 Availability

Stocked 1¼″ to 5″.

Plate sizes · W × L (in)

  • 96×288
  • 96×240
  • 96×192
  • 96×144
  • 96×120
  • 48×144
  • 48×96

Thinner than 1¼″? Ask about TASSCO XT, stocked 3/16″ to 1″.

Custom thicknesses, plate sizes, shape cuts, hole patterns, and forming on request.

Values are typical and for reference.
